Specification :

• Model : DA-2350
• Description : Two Channel Class-D Power Amplifier
• Speaker Output: 8Ω & 100V
• Input: 0.775V, 0dBu, balanced phoenix
• connector by two channels
• Input Impedance: 10KΩ
• Frequency Response:
• L/H Cut OFF 20Hz-20KHz (+1/-2dB)
• L/H Cut ON 70Hz-10KHz (+1/-3dB)
• Rated Power Output : 2x350W
• Speaker Output : 100V & 8 Ohm
• Frequency Response : L/H Cut OFF 20Hz-20KHz (+1/-2dB) L/H Cut ON 70-10khZ ((+1/-3dB)
• Input : 0.775V, 0dBu, balanced phoenix connector by four channels
• Input Impedance : 10KΩ
• THD : <0.1% (1KHz/-3dBv, 100W)
• S/N Ratio : >80dB
• Crosstalk : >60dB, 1KHz, Max output

• Power Supply : AC 115V to 230V, 50-60Hz
• Dimension : 484x420x44 mm
• Weight : 7.8kg
