Model

EVAC-500

Description

6 Zone Voice Evacuation Controller

Rated Power Output

500W

Fireman Microphone

5Mv, 600Ω

Line 1-2 Inputs

385mV, 10kΩ balanced Combo XLR

Line 3-6 Inputs

350mV, 10kΩ, RCA

Frequency Response

80Hz~20kHz

THD

＜1% at RMS,1KHz

S/N Ratio

>70dB

Speaker Output

100V AB 6 zone speaker outputs

REC Output

200mV

Control Input & Output

8 control inputs: Max 3.3V (voltage mode) or 0V closed contact;

8 control outputs: 0V closed contact;

1 fault, 1 reset & 1 EVAC relay outs

Voice Message

MP3 or WMA format, two separate players of SD card, programmable voice message up to 256, 10 years valid

Event Record

HEX format, Hard Flash memory, events up to 1000 records, 10 years valid

Operation Envr

Operation Temp: +5℃ ~ +40℃; Store Temp: -20℃ ~ +70℃; Operation Humidity: <95%

Power Consumption

650W

Power Supply

AC230V or 115V & 24V DC inputs, 50-60HZ

AC Fuse

250V/6.3A, slow type and restorable fuse

Dimension

484×132×449mm

Weight

23kg
